SIM daim npav qhov 4G CPE Router

HWM Basic information

CPU

ASR1826

MTK7621DA

RAM

CP: 1Gb LPDDR2; AP: 1Gb Embedded DDR3-1200 128MBytes (KGD)

ROM

CP: 1Gb Nand flash; AP: 1Gb Nand flash

Wifi

2, 4G, 5G

Kav hlau txais xov

Wifi kav hlau txais xov

PCB

RF Kav hlau txais xov

Sab hauv, sib xws nrog External kav hlau txais xov (SMA2)

Cov ntaub ntawv tus nqi

TDD{0}}LTE CA

※ 3GPP R10, Category 6, DL 300Mbps UL 100Mbps

FDD-LTE CA

※ 3GPP R10, Category 6, DL 224Mbps UL 50Mbps

TDD{0}}LTE

※ 3GPP R9, Category 4, DL 150Mbps UL 50Mbps

FDD{0}}LTE

※ 3GPP R9, Category 4, DL 150Mbps UL 50Mbps

TD-SCDMA

/

UMTS

※ 3GPP R7 DL 21.6Mbps UL 5.76Mbps

EDGE/GPRS

/

Kev teeb tsa WIFI Router

raws tu qauv

Max cov neeg siv 32

DHCP tus neeg siv khoom / tus neeg rau zaub mov, koj tuaj yeem teeb tsa seb puas yuav qhib qhov kev pabcuam DHCP muab IP chaw nyob pib thiab xaus qhov chaw nyob, teeb tsa lub rooj vag chaw nyob;
Txhawb nqa cov npe: Qhia tag nrho DHCP server kom tau txais IP chaw nyob ntawm tus tswv tsev, suav nrog MAC chaw nyob, IP chaw tau txais.

Txhawb lub davhlau ya nyob twg IP chaw nyob, SSID, kev sib txuas lus channel, hom kev ruaj ntseg, tus thawj tswj hwm tus account thiab tus password Hoobkas teeb tsa.

Txhawb SSID thiab channel nqis: Teem SSID, kev sib txuas lus channel (ntau zaus band WiFi teeb tsa, xaiv qhov ntau ntawm WiFi kev txhawb nqa ntawm cov qhab tag nrho cov channel muaj), WIFI muaj nuj nqi rau / tawm, thiab SSID tshaj tawm rau / tawm.

Muab WEP, WPA-PSK, WPA2-PSK, thiab lwm yam.

Txhawb MAC thiab IP filtering

Txhawb VPN

Firewall

Txhawb IP Chaw Nyob Lim

Txhawb Port Mapping/Trigger

Txhawb DMZ

Txhawb Dn Lim

HTTP hloov tshiab

Local HTTP server nyiam

OTA (HTTP/TR069)

HTTP nrog PC, TRO69

System Log

Tso saib qhov system thaum lub sijhawm ua haujlwm cov ntaub ntawv tsim tawm. Ib qho yooj yim rau cov neeg siv kom nkag siab txog cov cuab yeej siv los ntawm cov lus nug cav qhov xwm txheej uas tau tshwm sim rau. Tso cai rau tus neeg siv kom tshem tawm lub cav ua haujlwm.

Kev sib txuas -raws li

Tus poj niam

Firmware Update

Hloov tshiab online ntawm HTTP server; Local Update ntawm WebGUI

Yam yuav tsum tau ua

Routing Features

Choj hom, Transparent Bridging (Tsis yog-NAT)

Network Address Translation (NAT) Network Chaw Nyob Txhais Lus (NAPT)

Generic Routing Encapsulation (GRE)

Network Time Protocol (NTP) client/relay/server

Dynamic Host Control Protocol (DHCP) tus neeg siv khoom / server

Kev ruaj ntseg nta

Cheeb Tsam Tsis Muaj Tub Rog (DMZ)

VPN Client/Server/Pass{0}}los ntawm (IPSec, L2TP, PPTP, SSH, OpenVPN)

Taw tes - mus rau -Point Tunneling Protocol (PPTP), hla dhau

PPP hla Ethernet (PPPoE)

Authentifi cation, pap, chap and psk

Kev tswj hwm nta

Kev tswj hwm ntawm kab lus txib (CLI), SSH, SCP thiab HTTPS

Bandwidth Management/QoS

Lub zog nta

Ua hauj lwm voltage

12V

Max voltage input

15V

Roj teeb

/

ua hauj lwm tam sim no

TBD

Max ua haujlwm tam sim no

TBD

Environmental yam ntxwv

Ua haujlwm kub

0 degree - ntxiv rau 40 degree

Ua haujlwm kub heev

-10 degree - ntxiv rau 50 degree

Cia Kub

-20 degree - ntxiv rau 70 degree

txheeb ze humidity

10% -90% RH

Qauv

I/O

RJ45;

LTE SIM

Ib leeg

T-Flash Card

Tsis txhawb

Chaw nres nkoj

LTE SIM

Micro SIM

Ntsiab

Key1: Restore, key2: WPS; Nqe 3: Lub zog

Ethernet

LAN / WAN: RJ4511000M

LAN: RJ4531000M

PC OS

Kev them nyiaj yug: Win7/WinXP, MAC OS, Windows8, Android, LINUX
