300Mbps LTE FDD TDD 4g Wifi Router
1 * 10/100M WAN ntxiv rau 2 * 10/100M LAN ntxiv rau 1 SIM daim npav
Plug thiab ua si daim npav
4G rau wired network, 4G rau wifi
Xa kev nug
Product Details of300Mbps LTE FDD TDD 4g Wifi Router
300Mbps LTE FDD TDD 4g wifi router
7628R12 yog 300Mbps, 2.4G high-speed thiab high-performance 4G wireless router, uas muaj peev xwm muab cov neeg siv nrog wireless ntev-ntev, loj cov ntaub ntawv kis tau tus mob muaj nuj nqi los ntawm 3G / 4G network los ntawm ncaj qha inserting 4G SIM card.The proprietary thiab ruaj khov openwrt system muab ob lub 100M Ethernet LANs thiab ib qho 100M Ethernet WAN chaw nres nkoj.
Nws tuaj yeem txuas 32 ntxiv rau Ethernet li thiab WiFi khoom siv tib lub sijhawm kom paub meej cov ntaub ntawv sib kis thiab kev ua haujlwm.
Cov khoom siv tau dav siv hauv tsev / enterprisewireless broadband, kev thauj mus los, kev saib xyuas kev nyab xeeb, kev nkag mus rau aquaculture broadband, nyiaj txiag, thiab lwm yam lag luam.
Specification:
1) 300Mbps kev kub ceev Ua raws li EEE802.11b/g/n raws tu qauv.
2) Plug thiab ua si daim npav, daws teeb meem hauv internet.
3) Muab 1 * 10/100M WAN ntxiv rau 2 * 10/100M LAN ntxiv rau 1 SIM daim npav.4) 4G rau wired network, 4G rau wifi.
5) Ua tiav kev tiv thaiv kev poob qis kom ntseeg tau tias cov ntaub ntawv davhlau ya nyob twg yog nyob online.
6) WDT watchdog tsim kom muaj kev ruaj ntseg.
7) Txhawb Uboot txhuam.
8) Lub wireless standby tooj yog 30, HD video yog 4 ~ 5, wired yog hais txog 64.
9) Txhawb 64/128 ntsis WEP encryption, WPA/WPA2, SPA-PSK/WPA2-PSK thiab lwm yam kev encryption thiab kev ruaj ntseg mechanism.
10) Nws tuaj yeem siv tau yooj yim rau kev saib xyuas kev sib kis, 4K ntse TV, HD yeeb yaj kiab ua si, video online, 3D games, thiab lwm yam.
Network:
--4G:LTE-FDD: B1/B3/B7/B8/B20/B28(2100/1800/2600/900/800/700 MHz)
--4G:LTE-TDD:B38/B40/B41 (2600/2300/2500 MHz) --3G:DC-HSPA plus /HSPA/UMTS:B1/B8(2100/900MHz)
--Wireless hais lus: mus txog 300Mbps (2.4G)
--Kev xa hluav taws xob:<>
Nws tuaj yeem txuas LAN thiab WAN, muab 4G wireless router, Thiab yog cov khoom siv Internet ceev uas txhawb nqa 300M Ethernet kev sib txuas lus thiab WiFi LAN (802.11b / g / N) kev sib txuas lus. Muab cov neeg siv nrog cov kev pabcuam siab ceev, nyab xeeb thiab txhim khu kev qha broadband.
Khoom parameters | Piav |
Lub npe | MT7628 4G wireless router |
Zaus band (Aisa & Europe) | LTE-FDD: B1/B3/B5/B7/B8/B20/B28 LTE-TDD: B34/B38/B39/B40/B41 WCDMA: B1/B5/B8 GSM: 900/1800M |
Lub zog interface | DC 12V -1A |
Processor | MT7628 Main zaus 580M |
WLAN | Txheem: IEEE 802.11b / IEEE 802.11g / IEEE 802.11n 2 x 2, MIMO |
WIFI ceev | 2.4GHz WiFi: 300Mbps |
WIFI Ntau | 2.4GHz ceev |
Internet Chaw nres nkoj | 2- txoj kev RJ45 LAN * 100Mbps thiab 1- txoj kev RJ45 WLAN * 100Mbps |
4G Ceev | LTE CAT4 MIMO 2 * 2, Max 150Mbps (DL) Max 50Mbps (UL) |
SIM qhov | Standard SIM Card |
Pib dua khawm | Los ntawm lub pob no, qhov parameter configuration ntawm ROUTER tuaj yeem rov qab mus rau lub Hoobkas nqi |
Hom kav hlau txais xov | Sab nraud Kav hlau txais xov 4G MIMOX2 txog 150Mbps Sab Nraud WiFi MIMOX2 txog 300Mbps |
Kav hlau txais xov nce | 5dBi ib |
LED | Lub zog ntsuas X1 WAN kev twb kev txuas qhia X1 Qhov taw qhia WIFI X1 LAN1 qhov taw qhia X1 LAN2 qhov taw qhia X1 4G qhov taw qhia X1 |
Loj | 245 X 145 X 30 mm |
Qhov hnyav | 250g |
Plhaub | Dub, yeem |
Ua haujlwm kub | -25 ~ 60 degree |
Cia kub | -40 ~ 80 degree |
Ua haujlwm av noo | 15 feem pua -85 feem pua RH tsis-condensing |
Cia cov av noo | 10 feem pua -95 feem pua RH tsis-condensing |
IP chaw nyob | 192.168.1.254 |
Tus neeg siv / tus password | admin |
WiFi npe | wireless-XXXXXX (Lub xeem rau tus lej ntawm MAC tus lej) |
Lus | Suav/English |
Routing configuration | WEB interface tswj (HTTP) |
Kev tswj hwm thiab kev saib xyuas | WEB hloov kho dua tshiab, WEB kev tswj cov cuab yeej, Web nkag mus (chaw taws teeb / hauv zos), web administrator password, Wi-Fi SSID / configuration password, firmware hloov tshiab ntawm lub vev xaib, SSID tshaj tawm, rov kho lub Hoobkas nqis, |
LAN | Teem lub IP ntawm lub network sab hauv thiab sab nraud network (piv txwv li, qhov chaw nres nkoj wan txuas nrog txoj hauv kev sab saud kom tsis txhob muaj kev tsis sib haum xeeb IP, thiab ib pab pawg sib txawv ntawm txoj kev sab saud tuaj yeem teeb tsa ntawm no) |
DHCP server | Hloov kho LAN DHCP chaw nyob pas dej ua ke |
VLAN | Muaj peev xwm faib ntau VLANs thiab txhawb kev sib txuas lus ncaj qha ntawm cov khoos phis tawj |
QOS | Teem lub upstream thiab downstream bandwidth ntawm tam sim no network ceev, thiab teem lub davhlau ya nyob twg ntaus ntawv ua ke nrog tag nrho cov bandwidth tus nqi |
DDNS | Qhov kev teeb tsa no tuaj yeem ua raws li lub neej ntawd DDNS cov chaw muab kev pabcuam sau npe rau tus lej sau npe khi dynamic ip kom ua tiav kev tswj xyuas chaw taws teeb. |
Chaw nres nkoj xa mus | Internal Port Forwarding External Port Configuration Items |
VPN | Client configuration kev twb kev txuas txhawb L2TP PPTP raws tu qauv |
WPS | teeb wps rau thiab tawm khawm |
DMZ | Kev txhim kho thiab tsim cov cuab yeej qhia txog lub network ip rau sab nraud network |
Kev txheeb xyuas lub network | Xyuas seb 4G txuas nrog |
CPU npe | Ntxiv lub hostname thiab MAC chaw nyob ntawm lub cuab yeej kawg |
MAC chaw nyob | Teem cov npe dub thiab dawb ntawm lub davhlau ya nyob twg IP chaw nkag mus rau lub network |
IP chaw nyob | Teem cov npe dub thiab dawb ntawm lub davhlau ya nyob twg IP chaw nkag mus rau lub network |
Sau npe filtering | Teem cov npe dub thiab dawb ntawm cov neeg tuaj xyuas |
WIFI txoj kev npaj | Koj tuaj yeem hloov kho lub sijhawm kom qhib lossis kaw WIFI ntawm lub sijhawm |
Kev tswj chaw taws teeb | Qhov chaw nres nkoj rau kev tswj xyuas tej thaj chaw deb tuaj yeem nkag tau los ntawm kev paub txog WAN chaw nres nkoj IP thiab chaw nres nkoj (nco ntsoov tias WAN chaw nres nkoj IP yuav tsum yog tus IP network pej xeem) |
Sijhawm tsam | Xaiv koj lub sijhawm hauv zos thiab synchronize lub sijhawm hauv internet |
Saib | Tso cai rau kev teeb tsa ntawm lub sijhawm rov pib dua thiab / lossis thaum lub network txuas raug txiav rau lub sijhawm teev tseg |
Cov neeg siv ntau tshaj plaws | 32 |
OTE: Ntxiv rau qhov tsis tu ncua zaus bands, txawv teb chaws thiab cheeb tsam, tshwj xeeb zaus bands tuaj yeem hloov kho, thov hu rau cov neeg siv khoom!
